PRECISION FOR SMALL GOLD.
ONE MACHINE. ALL GOLD.
Commercial
Field Performance
Launch
POWER FOR DEEP GOLD. PRECISION FOR SMALL GOLD.
MAGNETAR 9000 is built to find both deep gold and micro nuggets in harsh mineralized ground. Its advanced pulse induction platform and dual-receiver coils deliver strong depth, sharp response, and stable performance in difficult conditions.
DEEP GOLD
SMALL GOLD
EXTREME GROUND
User-Friendly Interface Design
An intuitive color interface with bold, clear icons puts every function within easy reach — for faster, sharper control in every hunt.
Easy & Expert Modes
Start your way — choose Easy for a quick, guided setup, or Expert for full command over advanced settings.
Easy Mode
Pre-tuned settings let you power up and start detecting right away — no learning curve, no compromise.
Expert Mode
Take full control of every parameter — built for serious hunters who demand maximum performance in the toughest fields.
STOP CARRYING MULTIPLE DETECTORS.
One platform built for deep gold, small gold, and the toughest ground — no compromises, no second machine needed.
Connect it to Any Headphones
Built-in loudspeaker and Bluetooth audio give you the freedom to hunt your way — wired, wireless, or hands-free.
Magnetar 9000 Package Contents
Waterproof DRC Search Coil & Cover
14.5'' x 13'' / 37cm x 34cm (MG37)
Waterproof DRC Search Coil & Cover
11'' x 8'' / 29cm x 21cm (MG29)
Detectobag Backpack
Nokta Bluetooth Headphones & Charging Cable
2 x Lithium-Ion Batteries
Charger & 4 Plug Adapters
Vehicle Charger
Battery Clamp Charging Cable
Bungee & Hipstick
Nokta Standard Digger
1/4'' / 6.3 mm Headphone Adapter Cable
USB Data Cable
Magnetar 9000 Specifications
| Operating Principle | Advanced Pulse Induction |
| Search Modes | Easy & Expert |
| Search Coils | 14.5” x 13” / 37 cm x 34 cm (MG37)
11” x 8 ” / 29 cm x 21 cm (MG29) |
| Audio Output | Built-In Loudspeaker, Bluetooth & 6.3 mm (¼”) headphones socket |
| Display | Full color, 320 × 240 pixels, 49 mm × 37 mm (1.9″ × 1.5″) |
| Length | 150cm (59″) – 72cm (28″) collapsible |
| Weight | 2.4kg (5.3lbs) w/ 11” coil , 2.8kg (6.2lbs) w/ 14” coil including the battery |
| Operating Temperature Range | 0°C to 50°C (32°F to 122°F) |
| Operating Humidity Range | Up to 95% non-condensing |
| Storage Temperature Range | –20°C to 60°C (–4°F to 140°F) |
| Storage Humidity Range | Up to 98% Relative Humidity |
| Operating Time | Up to 10 hours |
| Waterproof Rating | IP68 up to 3m (10ft) |
Battery Technical Specifications
| Type | Li-Ion Rechargeable Battery Pack |
| Output Voltage Li-Ion | 7.2V DC |
| Capacity Li-Ion | 48Wh |
| Run Time | Up to 10 hours. Note: Up to 20 hours total with included 2x batteries. |
| Weight Li-Ion pack | 270g (0.6 lb) |
| Battery Operating Temperature | 0°C to 50°C (32°F to 122°F) |
| Battery Storage Temperature | −5°C to 70°C (23°F to 158°F) |
Battery Charger Technical Specifications
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Storage Temperature | −30°C to 80°C (−22°F to 176°F) |
| Input Voltage | 12 to 30 VDC |
| USB Output Current | 500 mA |
